| Liandong-U-Gu 17-2#, Shengyuan Road 1#, Jiangkou Street, Fenghua District, Ningbo City, Zhejiang Province, China | airwolf@flyautomatic.com |
 |
| Brand Name: | FESTO |
| Model Number: | ADVUL-50-50-P-A |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | EXW USD100-120 |
| Packaging Details: | plastic bag, carton，OPP bag |
| Delivery Time: | 7-10 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 800 pcs per month |
| Type: | ADVUL-50-50-P-A | Part No: | 156900 |
|---|---|---|---|
| Brand: | FESTO | Ambient Temperature: | -20°C-80°C |
| Mode Of Operation: | Double-acting | Corrosion Resistance Class CRC: | 2 - Moderate Corrosion Stress |
| Highlight: | 156900 Pneumatic Air Cylinders,Pneumatic Air Cylinders Compact cylinder,156900 Compact cylinder |
||
About product
Technical Data
| Stroke | 50 mm |
| Piston diameter | 50 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston Piston rod |
| Position detection | Via proximity switch |
| Symbol | 00991737 |
| Variants | Piston rod at one end |
| Protection against torque/guide | Guide rod with yoke |
| Mode of operation | Double-acting |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20°C-80°C |
| Pneumatic connection | G1/8 |
| Material collar screws | Galvanised steel |
| Material cover | Wrought aluminium alloy |
| Material dynamic seals | NBR TPE-U(PU) |
| Material piston rod | High-alloy steel |
| Material cylinder barrel | Wrought aluminium alloy |
Dimensions – Basic cylinders
FESTO cylinder has good stability, quality, and long service life, making it your best choice.
